Introduction

Randomized algorithms use functions that return a pseudo-random number in a given range or a random element from a given set. In some cases, when this function is used only a few times, the use of automated testing becomes feasible, because it is possible to execute the algorithm simulating several return values for the random functions under consideration.

However, if the random function is used several times or a variable number of times, it is not reasonable to simulate the value of several calls. Therefore, it is not practical to simulate all of these paths to test a randomized algorithm with several random choices. Moreover, even if it were feasible to simulate all these answers, they would not be truly random. As any code with a lack of tests, when these algorithms need maintenance, or new solutions need to be developed, faults can be inserted into the system without notice.

TDD is a software development technique in which tests are developed before the code, in short and incremental cycles Guerra and Aniche This technique proposes for the developer to create a new flawed test, and then to implement a little piece of code, in order to satisfy the current test set. Then, the code is refactored if necessary, to provide a better structure and architecture for the current solution Beck ; Astels TDD is traditionally used with deterministic algorithms when there is a known input and one expected result.

The challenge addressed in this work is to use TDD in applications with non-deterministic behavior as stated before. Although it is not possible to know exactly what the output will be, it is usually possible to check whether the generated output is valid or not. The following factors make it difficult to develop randomized software using TDD: a results for each execution may be different for the same inputs, which makes it difficult to validate the return value; b obtaining a valid return for a test case execution does not mean that valid return will be delivered on the next executions; c the random decisions and their paths number make it not viable to create Mock Objects Mackinnon et al.

In this paper, we present 1 an approach that allows an extension of TDD for its application in algorithms with non-deterministic characteristics, and 2 a framework for the JUnit called ReTest Ivo and Guerra b , developed by the authors in order to support the random algorithms testing. In short, the proposed approach uses multiple verification to validate of the algorithm return and executes each test several times with different seeds to increase test coverage.

From the result of these repetitions, the seeds from pseudo-random test cases that generated failures are stored and used in future tests, ensuring that a scenario where an error was detected in the past is executed again. The paper is organized as follows. Section 2 introduces the background necessaries knowledge. Section 3 describes the method we applied in this research. Section 4 presents our approach outlined from a set of patterns that assist in the test automation of randomized algorithms. Section 5 presents a single-subject experiment of an implementation that used the proposed approach.

Section 8 presents the discussion and limitations of the research. Finally, Section 9 presents the conclusions and future perspectives. In this section, we present concepts and techniques related to the approach for applying TDD in the development of randomized algorithms.

Shop now and earn 2 points per $1

Section 2. Many algorithms might consider, at some point, one or more random steps during their executions. For instance, algorithms used to find an approximate solution to NP-Hard problems or Monte Carlo Algorithm, usually take random choices into account.

Monte Carlo Algorithms: define a class of algorithms that generally run quickly and return the correct answer with high probability, albeit, it might return a wrong answer. Las Vegas Algorithms: which are those algorithms that always return a correct answer, but running time is random, although finite Galbraith The algorithm used in the study to verify the viability of our approach Section 5 is the Las Vegas type algorithm that always gives to a correct answer or so the proposed technique guarantees , but performs at random time. Using a graph as input, the algorithm applies a random sequence of transformations, and the output should be a graph that has some specific metrics.

Notwithstanding, the approach proposed in this study can be applied to both classes of randomized algorithms. Finally, it should be stated that the stochasticity or non-determinism considered here are not related to the theoretical concept of non-determinists algorithms. These non-determinists algorithms rely on the architecture of a non-deterministic Turing Machine Floyd In our scenario, non-determinism is related to the stochastic behavior of the algorithm.

TDD is a code development and design technique, in which the test code is created before the production code. There are several works reported by Guerra and Aniche see Guerra and Aniche that indicates that the use of TDD can improve source code quality. One of the reasons for the popularization of TDD is its explicit mention as part of the agile methodology Extreme Programming XP Beck and Andres , however today it is also used out of this context.

In TDD practice, the developer chooses a requirement to determine the focus of the tests, then writes a test case that defines how that requirement should work from the class client point of view. Because this requirement has not yet been implemented, the new test is expected to fail. The next step is to write the smallest amount of code possible to implement the new requirement verified by the test. At this point, the added test, as well as all other previously existing tests, are expected to run successfully.

Once the tests are successfully executed, the code can be refactored so that its internal structure can be continuously evolved and improved. The tests help to verify if the behavior has not been modified during refactoring. With the use of TDD, the code design is defined in cycles. The idea is that with each new test added, a small increment of functionality is made compared to the previous version. JUnit is a Java open-source framework for the creation of unit tests.

Its purpose is to be a basis for the creation of test automation code. It is used for the practice of TDD, and its model has been taken into account to create test frameworks for other languages. Some of the main features of these frameworks are the execution of test cases and the presentation of the execution results Beck and Gamma JUnit, since version 4, provides extension points that allow the introduction of new functionality. Some of the most important JUnit extension points are represented by the classes Runner and Rule.

In this way, to implement a new test runner it is necessary to create a new class extending Runner. To use it in a test class, the annotation RunWith should be configured receiving in its attribute value the new class that replaces the default test runner. If it is necessary to extend the existing functionality, the new runner should extend the BlockJUnit4ClassRunner class.

Another JUnit extension point is known as Rule and it allows the addition of new behaviors mainly before and after the execution of each test. To introduce a new Rule, it is necessary to create a class that implements the TestRule interface. To use it, a public attribute should be declared in the test class and annotated with Rule , as shown in Listing 1.

In the example shown in Listing 1, when executing the test project, the newRule is called before and after the testMethod. The annotation Rule is responsible for adding the desired behaviors before and after each test. The need of this research was raised during the development of a randomized algorithm in the National Institute of Space Research.

The developer was familiar with the TDD technique but did not know how to apply it in that context. Based on that need from a real implementation the approach was developed. The proposed approach was initially evaluated in a feasibility study, performed through a single-subject experiment that used the algorithm that motivated its development. Single-subject studies are one way to provide empirical support for software-engineering techniques, in which only one subject performs the tasks in the study Harrison In this single-subject experiment, our approach was applied in the algorithm implementation involving multiple random decisions in sequential performing.

The results of this implementation using our approach was compared to the same algorithm previous implemented in the traditional way, using the same programming language and without unit tests. Information about the effects of using and not using the approach was provided by the researcher, the single subject who implemented twice the same algorithm. The set of practices identified as the core of the proposed technique were documented as three patterns Ivo and Guerra a. The published paper focused on practitioners and provided a detailed description of each pattern. It has a different goal from the present paper that focuses on the research involved in the development and evaluation of the approach.

Based on the documented practices and in the experience of using the approach for a complex algorithm implementation, a testing framework for Java called ReTest was developed. This framework has features that make easy the usage of the proposed approach, such as the generation of seeds, the repetition of test execution and the support for re-executing previous failed tests.

After the framework implementation, we performed a study to evaluate the applied approach with the support of the ReTest framework in terms of ease of use, usefulness, perceived benefits, drawbacks, and difficulties. In this study, 10 participants implemented a simple algorithm using the ReTest framework for tests and following an established procedure to guarantee the application of TDD.

At the end of the activity, a questionnaire with open and closed questions was used to gather the opinion and perceptions of the developers-participants regarding their experiences with the use of the framework in the implementation task. In general, existing test techniques are suitable for applications with deterministic algorithms, when one has a known entry and an expected result.

More traditional testing strategies often focus on exploring the input domain by evaluating the values used as input and obtained as outputs to find combinations of input parameters that can cause failures. Several testing techniques focus on indicating a set of tests necessary to a proper coverage of the input domain. Combinatorial testing , for example, combines all possible rearrangements of the input parameters and submits this list to the algorithm to be tested Anand et al. Unfortunately, the coverage of the input domain is not enough for randomized algorithms, because even for the same input the result can be different.

In other words, a successful execution might fail in the next time it is executed with the same inputs. In order to automate tests of randomized logic, we have proposed an approach based on three software patterns: Deterministic Characteristic Assertion - to create an assertion that verifies the validity of the algorithm result; Re-test With Different Seeds - to execute the test several times with different seeds; and Recycle Failed Seeds - to persist seeds used in failed tests to be reused in future test executions.

Next, we present an overview of each pattern. And, after the explanation of the patterns, we present the application of the proposed approach through an illustrative example. The Deterministic Characteristic Assertion pattern proposes the usage of assertions based on a criteria that verifies deterministic characteristics of the result at the end of the execution.

If all criteria are met, the results can be considered valid. This pattern can be associated with test oracles. This pattern is related to how the assertion should be performed, and it is related to the correctness of the algorithm. In theoretical computer science, the correctness of an algorithm is asserted when the algorithm is correct concerning a specification. Functional correctness refers to the input-output behavior of the algorithm i.

The solution is summarized in the selection of fundamental characteristics that determine the validity of the algorithm result. An analysis of the algorithm should be performed with the intention of identifying the main requirements and behaviors that do not change in a valid result. Then, these items should be related to a list of deterministic characteristics that can be verified. For each deterministic characteristic, an assertion procedure should be developed. After developing the set of characteristics verification, the algorithm should be executed, and its result submitted to the assertion set.

If all set of characteristics tests run successfully, it means the output is valid, regardless of its exact value. In general, there is an intention of evaluating the behavior of the algorithm independently of the outcome. In some cases, it is possible to extract the characteristics of the result itself, in others, it is not.

As a good practice, there may be cases where it is necessary to divide the algorithm into some parts so that it is possible to isolate the randomized parts and to verify deterministic characteristics from its intermediate results. This pattern is focused on increasing test coverage, which is not the same thing as functional correctness, which is covered by the Deterministic Characteristic Assertion pattern.

Test coverage is not an aspect of product quality; it is just one measure of how well exercised a product is. Thus, broader code coverage correlates with fewer expected undiscovered product bugs. For this reason, the proposed approach applies this pattern combined with Deterministic Characteristic Assertion.

To use this pattern, the developed algorithm should be able to receive the object used to generate the pseudo-random inputs or the seed that should be used. The test using Deterministic Characteristic Assertion pattern should be executed several times varying pseudo-random inputs generator or its seed. The seed for each execution can also be implemented using a pseudo-random input generator. In general, a library with functionality to generate pseudo-random values based on a seed is present in several programming languages.

The combination of pseudo-random inputs and the number of repetitions causes the algorithm to be exercised traversing different paths. So, the larger is the number of repetitions, the wider is the code coverage.

Additional Material:

For cases where the complexity of the code and the number of features is high, it is recommended to increase the number of repetitions to generate a more extensive code coverage. It is important to state that the use of this pattern does not guarantee that the tests will cover all possibilities. However, especially in an environment where the tests are frequently executed, after several executions, it is possible to have good coverage, providing confidence that the algorithm is implemented correctly.

This pattern is used to enable the re-execution of test cases that failed in previous executions. One of the most significant problems in randomized algorithms is debugging, since its stochastic behavior makes the reproduction of an error a complex task. This feature makes it hard to apply specific modern techniques in software quality, for example, regression tests. Regression testing may become very large during the process of integration tests. Thus, it is unpractical and less efficient to re-run all the tests for each modification Xiaowen Because of these difficulties, alternative approaches to the Regression Test Selection RTS technique has been proposed in Agrawal et al.

RTS approach recommends that only a select subset of the tests be run to optimize and minimize the time of the execution. This subset must be selected according to the need and characteristics of the software system being developed Kim et al. As a complete solution for tests of randomized algorithms, as well as Adaptive Random Testing ART , this article proposes the division of the input domain into two sets.

However, unlike ART, the first set of the input domain is only a projection of the actual test cases, the second set is the test cases that have presented errors in executions. To get the first set of the input domain, one must use the pseudo-random generations as presented in the Re-test With Different Seeds pattern. To obtain the second set of the input domain, the seeds associated with the failed tests should be preserved.

Select the seeds from the failed tests, and perform new tests with these seeds, inducing the randomized algorithms to repeat the same paths and behaviors that led to failure. Like the Re-test With Different Seeds pattern, this pattern is focused on increasing code coverage. Each of the possibilities presents a path that must be tested, so the amount of testing rises exponentially with the number of possibilities.

In fact here the question is not the number of possible answers, but the fact that there are several correct answers and the algorithm can return different answers to each execution. The Listing 2 shows a simple example of how to use the proposed test approach. These functions represent the point where all assertions of the characteristics are performed. The second software pattern Re-test With Different Seeds is represented by a software loop. On the Listing 2, the use of this pattern can be observed in the first for statement.

The focus of this pattern is to increase the code coverage and for a better performance functional correctness should be used in conjunction with the pattern Deterministic Characteristic Assertion. For this reason, the assertion methods are invoked inside this loop. Listing 2 also demonstrates how to use the Recycle Failed Seeds pattern, the third software pattern proposed.

This pattern proposes to save the seeds when the characteristics assertion fails, so the same seeds can be used later in future executions. Still in Listing 2, the invocation of the method saveFailureSeed represents the logic to save the seed. The seed can be saved in memory, in a file or even in a database, depending on the test requirements. In Listing 2, the second part of the input domain is represented by a loop with the failed seeds, implemented in the second for statement.

Using TDD and trying to make a simple calculator. (Java in General forum at Coderanch)

Inside the loop, note that the input values are generated through a pseudo-random mechanism that receives the seed that failed as a the parameter, which then reproduces the same inputs, inducing the same behavior in the test. In this section, we report the results of the first study investigating the effects of proposed approach applied for implementation of a complex randomized algorithm involving the creation and evolution of dynamic graphs. First, we provide an overview on domain and related concepts, giving an idea about the complexity of the problem handled.

Then, we describe the single-subject experiment carried out by the researcher proponent of the algorithm for dynamic graphs and, finally, we report the results of this study. A dynamic graph is a graph that is constantly changing. They are those in which their elements, vertices, and edges, are constantly being added or deleted. The benchmark proposes a controlled dynamic environment by providing functions that simulate transformations that may occur in a graph considering its structure in communities. The community structure of a graph is a metric that can be used to cluster its vertices.

One can define which groups of vertices form a community through the comparison between the density of the graph and the density of the group. The density is calculated considering the number of edges within the vertices of the community, where more edges mean higher density. Possible changes that a community can suffer Porto and Quiles The algorithm described in this study creates a sequence of graphs, each containing its own structure in communities, to simulate the behavior of a dynamic graph.

Dynamic communities algorithm is composed of six functions that simulate these behaviors, named: born, growth, extinction, contraction, merge, and split. Hence, the output this algorithm is a graph that passes through a sequence of random changes considering the six possible functions stated before; this response must have specific properties. The properties are some topological measurements extracted from the graph. The output graph must preserve the measures of the input graph according to some previously established parameters.

Here, the measurements are the average degree of the network and the maximum degree, in which the degree of a vertex is the sum of the number of edges connected to it; the mixing parameter, which controls the fraction of edges that a vertex shares with vertices belonging to other communities; and, finally, the minimum and maximum size of the communities. While it is simple to check these properties, it is not trivial to implement an algorithm that generates a final graph that complies with them.

As a consequence, there must be a test routine to facilitate and give confidence to the code. However, in addition to the challenges already mentioned above, another challenge to test algorithms treated in this work is the input domain Elva The input domain is any possible combination of all input parameters of a method. However, if the parameters can be chased from an infinite set, which is the case in this experience, it means that the input domain is also infinite.

Therefore, not every possible combination is available. As already stated, the algorithm output is a graph which undergoes a sequence of random changes using the six possible change functions. The input of each function is also a graph, so the output of one function can be used as input to the next one, without any interference. However, in the tests, each output is checked whether it is under the properties established before, and it is used as input to the next function. Randomness plays an important role in the algorithm. The six functions aim to create a dynamic network with community structure evolution, step by step, to serve as a benchmark for community detection algorithms.

It means that the randomness is not only a consequence of the way the algorithm has been implemented but a requirement. Each function, born, extinction, growth, contraction, merge, and split will perform a series of modifications in the network. Such modifications involve adding and removing vertices and edges of one or more communities. Also, despite the algorithm having control of which are the vertices and edges of the network that may undergo such changes, the number of times that they occur is decided only at runtime.

The only estimate one can make is that this amount is proportional to the number of vertices that are being treated by the function. For example, the merge function first chooses how many first random decision communities will undergo changes, which can be at least two and up to all the communities. Then choose which second random decision communities will merge with which. From there, it sums up the total amount of vertices in the communities and calculates the minimum expected number of edges density to merge the selected communities. Then, pairs of vertices are selected multiple random decisions in sequence and become adjacent until the desired density is achieved.

Randomness was present in all steps of the merge function, as described in the previous paragraph, and is also present in all other functions. The first and second random decision of the merge function define how many decisions will be made after and the same principle applies to all other functions as well. This is a significant problem when testing computer code, after all, before running there is no indication of how many arbitrary decisions will be needed. It is only known that this quantity will be proportional to the number of vertices treated in the function.

Furthermore, even this amount is only determined at runtime. From the input graph, each function generates a sequence of graphs that correspond to the evolution or transformation of the graph in time. Thus, community detection algorithms can be tested in the most diverse situations regarding the order of application of each one of the six functions of the algorithm.

Ideally, this order must be as random as possible, as well as the number of transformations. Both order and quantity are chosen at runtime. A single-subject experiment was performed to verify the feasibility of the approach proposed to applying TDD in the development of the randomized algorithm for creation and evolution of dynamic graphs. The task assigned to researcher-developer was to implement the Dynamic Communities Algorithm using our approach, which had originally been implemented by herself in R programming language R Core Team in a traditional way.

The participant received previous training on TDD which consisted of theoretical classes and practical exercises, during a course in software design at the INPE. On this occasion, the approach to using TDD with randomized algorithms was presented. The independent variables of the study are 1 the programming language, 2 the randomized algorithm, and 3 the developmental approach that is also the treatment variable.

The objectives dependent variables observed in this study are: lines of code, number of functions, lines of code per function, lines of test code, and number of test cases. This procedure is known as an A-B design Harrison As aforementioned, the Dynamic Communities algorithm was twice implemented.

Regarding implementation time, in the first time, the researcher-developer took approximately three months to implement the algorithm in the traditional way, using R as the programming language A Phase. In this phase, the long implementation time was due to the fact that the solution was not well defined from the beginning.

During this implementation, a period of research was necessary to study the application requirements and define the logic that would be employed.

The Specimen Problem

In the second time, the researcher-developer took approximately three weeks to implement the algorithm using the same programming language, but this time following the proposed approach to the use of TDD with randomized algorithms B Phase. Less time was needed in this phase since the research had already been consolidated with a well-defined algorithm. The implemented code is hosted on GitHub 1. In the second implementation, the output graph the last one in the sequence is tested for its metrics, being the average degree, maximum degree, mixing parameter and size of the smallest and largest graph community.

The mentioned metrics form the group of characteristics that are evaluated in the output. That is, in this case, is employed the Deterministic Characteristic Assertion pattern, as described in the Section 4. Furthermore, if the graph passes all tests, it is used as input to the next function; if not, the seed used is stored to be used in the regressions tests, employing Recycle Failed Seeds pattern, as described in the Section 4. All of these metrics must be within a previously established threshold for the graph be considered correct.

Note that the Re-test With Different Seeds pattern was not used in this implementation because it met a very specific situation. Listing 3 summarizes the tests applied in each experiment. First, the seeds of this battery of tests are chosen, the randomness of the choice is to fulfill the Re-test With Different Seeds pattern Section 4. Each seed is an increase on the test coverage. For each seed, an initial graph is created and tested. Then, the size of the sequence of functions is chosen. For each function to be applied in the current graph, the output is tested.

If any test fails during execution, the seed is stored. The initial set of seeds can be altered to receive the set of seeds that led to errors. The tests performed in each graph, besides checking the metrics already mentioned, also make specific checks considering which function was applied. For example, if the born function was used, one community with a specific size number of vertices was added to the graph, so it is necessary to verify if the number of n c communities increased by exactly one unit and if the number of vertices in the graph increased precisely the size of the new community.

In the extinction function, the inverse applies, one community with a specific size was eliminated of the graph, so one needs to verify if the number of communities decreased by exactly one unit and if the number of vertices decreases the size of the community eliminated. In the growth and contraction functions, it is necessary to verify if the number of communities has remained, but the number of vertices has increased or decreased.

In the merge and split functions, it is necessary to verify if the number of vertices remained the same, after all, only the edges are modified in these functions, but the number of communities must decrease or increase. At this point, the researcher-developer highlighted that some situations which could lead to errors had not been detected during the first implementation. Such as a empty graph as input, b graph with only one community as input, and c pre-checking the value of the mixing parameter before changing any edges.

The latter situation allowed the algorithm to become more efficient. The researcher-developer recognized that such improvements were only possible with the use of our approach. This more granular division of the code favors the testing activity since it is easier to evaluate the behavior if the function has a more limited scope. Smaller and more granular functions also indicate that the code in B Phase have a better design and it is easier to maintain. An increase in the number of lines of code can also be noticed by comparing the two implementation phases. Despite the additional code for handling scenarios that were not considered in the initial version, this increase could also be justified by the developer attention to code readability.

With automated tests, it was safer to refactor the code continuously during its implementation. Additionally, the organization of the tests also helped in the verification and validation of the results, comparing them with other results of the literature. This framework provides its users a mechanism for managing the seeds used to generate random data in the algorithm being tested. Consequently, the same test can be repeated using the seeds used in previously failed executions. These features facilitate the application of TDD for the development of randomized algorithms. It should be mentioned that the framework does not have any feature to implement the pattern Deterministic Characteristic Assertion since it is something very specific to each algorithm.

In the test methods, the developer needs to include annotations to configure how it should be executed and annotations in the parameters that need to receive values generated and managed by the framework. The framework managed parameters are meant to be used as input data for the tests. The Listing 4 shows a simple example of use. In the code shown in Listing 4, the test method is marked with the ReTest 10 annotation, which configures the framework to execute it 10 times. At each execution, the framework will initialize the parameter marked with RandomParam received by the test method with a different seed.

Notice that this object is passed as an argument to the method being tested, called nonDeterministicAlgorithm. The class Random is used internally by the test method for the generation of its random numbers and, consequently, as a basis for its stochastic decisions. The assertResult is used to verify whether the return of the algorithm is considered valid. This test will be executed multiple times with Random initialized with different seeds, simplifying the execution of a large number of scenarios.

That way, by running the failed tests again, you can check that the error has been corrected in addition to maintaining a set of regression tests. Since in TDD the tests are executed frequently, throughout the development process the test executions should achieve good code coverage. This is reinforced by the fact that the tests that have failed previously are always executed again, enabling the debugging for a specific test scenario. In addition to the common JUnit annotations, the ReTest framework has a set of 4 annotations for the test methods and 4 annotations for the method parameters.

ReTest : This annotation is responsible for performing the test repetition. In this annotation it is possible to indicate how many times the test method should be executed;. SaveBrokenTestDataFiles : When you mark a method with this annotation, the input data will be saved to the file when the test fails;. SaveSuccessTestDataFiles : When you mark a method with this annotation, the input data will be saved to file when the test is successful;. LoadTestFromDataFiles : When you mark a method with this annotation, the input data from this file will be loaded and used in the execution.

IntegerParam : Annotation indicates that the ReTest framework should pass as a parameter a random integer;. Furthermore, if the graph passes all tests, it is used as input to the next function; if not, the seed used is stored to be used in the regressions tests, employing Recycle Failed Seeds pattern, as described in the Section 4. All of these metrics must be within a previously established threshold for the graph be considered correct.

Note that the Re-test With Different Seeds pattern was not used in this implementation because it met a very specific situation. Listing 3 summarizes the tests applied in each experiment. First, the seeds of this battery of tests are chosen, the randomness of the choice is to fulfill the Re-test With Different Seeds pattern Section 4. Each seed is an increase on the test coverage. For each seed, an initial graph is created and tested. Then, the size of the sequence of functions is chosen. For each function to be applied in the current graph, the output is tested.

If any test fails during execution, the seed is stored. The initial set of seeds can be altered to receive the set of seeds that led to errors. The tests performed in each graph, besides checking the metrics already mentioned, also make specific checks considering which function was applied. For example, if the born function was used, one community with a specific size number of vertices was added to the graph, so it is necessary to verify if the number of n c communities increased by exactly one unit and if the number of vertices in the graph increased precisely the size of the new community.

In the extinction function, the inverse applies, one community with a specific size was eliminated of the graph, so one needs to verify if the number of communities decreased by exactly one unit and if the number of vertices decreases the size of the community eliminated. In the growth and contraction functions, it is necessary to verify if the number of communities has remained, but the number of vertices has increased or decreased. In the merge and split functions, it is necessary to verify if the number of vertices remained the same, after all, only the edges are modified in these functions, but the number of communities must decrease or increase.

At this point, the researcher-developer highlighted that some situations which could lead to errors had not been detected during the first implementation. Such as a empty graph as input, b graph with only one community as input, and c pre-checking the value of the mixing parameter before changing any edges. The latter situation allowed the algorithm to become more efficient. The researcher-developer recognized that such improvements were only possible with the use of our approach. This more granular division of the code favors the testing activity since it is easier to evaluate the behavior if the function has a more limited scope.

Smaller and more granular functions also indicate that the code in B Phase have a better design and it is easier to maintain. An increase in the number of lines of code can also be noticed by comparing the two implementation phases. Despite the additional code for handling scenarios that were not considered in the initial version, this increase could also be justified by the developer attention to code readability. With automated tests, it was safer to refactor the code continuously during its implementation.

Additionally, the organization of the tests also helped in the verification and validation of the results, comparing them with other results of the literature. This framework provides its users a mechanism for managing the seeds used to generate random data in the algorithm being tested. Consequently, the same test can be repeated using the seeds used in previously failed executions. These features facilitate the application of TDD for the development of randomized algorithms.

It should be mentioned that the framework does not have any feature to implement the pattern Deterministic Characteristic Assertion since it is something very specific to each algorithm. In the test methods, the developer needs to include annotations to configure how it should be executed and annotations in the parameters that need to receive values generated and managed by the framework.

The framework managed parameters are meant to be used as input data for the tests. The Listing 4 shows a simple example of use. In the code shown in Listing 4, the test method is marked with the ReTest 10 annotation, which configures the framework to execute it 10 times. At each execution, the framework will initialize the parameter marked with RandomParam received by the test method with a different seed. Notice that this object is passed as an argument to the method being tested, called nonDeterministicAlgorithm. The class Random is used internally by the test method for the generation of its random numbers and, consequently, as a basis for its stochastic decisions.

The assertResult is used to verify whether the return of the algorithm is considered valid. This test will be executed multiple times with Random initialized with different seeds, simplifying the execution of a large number of scenarios. That way, by running the failed tests again, you can check that the error has been corrected in addition to maintaining a set of regression tests.

Since in TDD the tests are executed frequently, throughout the development process the test executions should achieve good code coverage. This is reinforced by the fact that the tests that have failed previously are always executed again, enabling the debugging for a specific test scenario. In addition to the common JUnit annotations, the ReTest framework has a set of 4 annotations for the test methods and 4 annotations for the method parameters.

EMBERCONF 2015 - TEST-DRIVEN DEVELOPMENT BY EXAMPLE

ReTest : This annotation is responsible for performing the test repetition. In this annotation it is possible to indicate how many times the test method should be executed;. SaveBrokenTestDataFiles : When you mark a method with this annotation, the input data will be saved to the file when the test fails;. SaveSuccessTestDataFiles : When you mark a method with this annotation, the input data will be saved to file when the test is successful;. LoadTestFromDataFiles : When you mark a method with this annotation, the input data from this file will be loaded and used in the execution.

IntegerParam : Annotation indicates that the ReTest framework should pass as a parameter a random integer;. RandomParam : This annotation indicates that the framework should pass an instance of an object of type Random, with a known seed, so that it can be stored and retrieved from files, making it possible to reconstruct the same test scenario;. SecureRandomParam : This annotation indicates that the framework should pass an instance of an object of type SecureRandom, with a known seed, so that it can be stored and retrieved from files, making it possible to reconstruct the same test scenario;.

Param : This annotation allows the developer to indicate custom randomizers for the specific data types in the application domain, allowing the extension of the framework for the random generation of several types of data. As mentioned earlier, TDD is not a technique normally used in the development of randomized algorithms, which depend on various random decisions made during their execution.

Thus, one of the goals of the ReTest framework is to make the use of this technique feasible for these scenarios. Store information of the failed scenarios to enable the verification if the changes in the production code make the failed scenario to pass;. Develop the simplest solution that makes the test suite run successfully for all inputs;.

Run the test cases several times including new random generators with new seeds and with seeds that failed in previous test executions;. Refactor, if necessary, to provide a better internal structure for the final solution;. In this cycle, the steps of the original TDD, presented in section 2. New steps were added as extensions proposed by the use of the ReTest framework, in order to ensure that TDD can be used as an application design technique and for generating automated tests for randomized algorithms.

The first test asks the method to create an array with size 1. Since there is only one valid response for this case, which is 0, it is not necessary to use any ReTest annotations;. It is written as the method implementation the return of a fixed value, and the test is executed successfully;. The second test introduced invoke the method passing the parameter to create a size 2 array, initially checking only if the response has the appropriate array size. At the first moment the test fails, because of the method in returning an array of size 1;. As an initial implementation, an array of the size passed as a parameter is created and a random value generated within the range of to 10 is set for each position;.

When executed, the tests pass, but it is known that the validity of the response is not being verified correctly;. The code is changed so that the last array value is not randomly generated, but is the value that makes the sum to be equals to zero. The tests are run and now all pass successfully;. The TDD process follows by having all the test running in the 3-element array generation scenario, and then placing the annotations so that failed executions are stored and included in the regression tests;.

From the example, it is possible to have a more concrete vision of how ReTest can be used to support the use of TDD in the development of a randomized algorithm. Note that test cases are gradually being introduced and implementation is also occurring incrementally. The first point to emphasize is that when a test that needs to be repeated is executed, its execution is only considered correct when in all cases success is obtained.

Note in Fig. In this case, the repetition functionality of the framework is important because in each execution of the test suite it is possible to repeat the same test several times. Another important point is in storing the seeds that generated failed test scenarios. Although it has not been commented, in the development of the example, in some cases modifications in code lead previous tests to fail in some scenarios.

In this case, it was important to have the same test scenarios executing again to make sure that the problem was solved.

Tag Archives: TDD

This section describes a study carried out to assess our approach from the software developer experience, applying it through the ReTest framework. Initially, the idea was to perform a comparative study to the development with TDD without a previous knowledge of the proposed approach. However, in the first attempt to conduct an experiment, most participants claimed that they did not know how to use TDD to develop a randomized algorithm.

Additionally, we also considered that a comparative study with participants using the proposed technique with and without ReTest would not be fair since the framework automates the steps that would be manually implemented without it. Based on that, we decided to perform a study to investigate whether the proposed approach could be used successfully by developers, assessing their experience when using it. Does the proposed approach supported by ReTest framework can be efficiently applied by less experienced developers?

What were the main difficulties encountered by the developers using the proposed approach? What are the benefits and drawbacks of the proposed approach from the point of view of the developers? Ten participants were selected among enrolled in graduate courses in the field of software design at the National Institute of Space Research. As a requirement, in order to participate in the study, the participant needs to have experience in programming using Java language and knowledge of code annotations. Nevertheless, all the participants received a training about TDD in order to homogenize their knowledge.

This training involved 16 hours of theoretical classes and practical code exercises on the course of software design at the INPE. When preparing the activities of the study we considered two key requirements: a an algorithm that is easy to understand and develop; and b to ensure that everyone executes the task based on TDD concepts. Set aside a time between 1 and 2 hours when you can perform the task without interruption and seek a quiet environment where you can focus on the task. Use a time marker stopwatch and start timing the task at that time.

The accuracy of the time marking can be in minutes. If there are unavoidable interruptions during the task, stop the time and resume when you return. Record how long you needed to interrupt your task this will be asked later in the questionnaire. In the last part of the questionnaire, the participants had to highlight the benefits and drawbacks of the proposed approach based on their experience. In addition, they needed to report whether the framework could be used in other applications.

There was also an open text field on this form in which participants could use to add any other comments. To answer the research question RQ1, we have considered the amount of time spent completing the task by each of the participants, who were divided into two groups according to their professional experience.

The implementation task was based on the illustrative example presented in the Section 4. In this problem, non-determinism is represented by the Random object, which at each execution will have a different and undetermined seed. Verify that the value of this index could be changed to a value between and 10 that would make the sum closer to or equal to zero;.

Verify that the value of the array at that index has the same sign as the sum and, if it does, generate a random number with the opposite sign within the range of and 10, assign the array to the index and update the value of the sum which will cause the sum value to closer to zero. Develop a test that ensures that the method creates an array of size 1. In this case, there is only one valid return that is 0;. The second test introduced should ensure that the method creates an array of size 2, initially checking only if the response has the appropriate array size.

At first, the test should fail because the method only returns the array of size 1;. Run the tests. At this point in development, the tests must be passing, but it is known that the validity of the response is not being verified;. Then create an assertion helper method to check the validity of the output. This method checks if the array has the expected size, if the value of each element is in the range of to 10, and if the sum of the elements is equal to zero;.

The ReTest annotation must be used for this test method to run 10 times;. Change the method code so that the return is as expected and for all tests to run successfully;. Create at least 3 more tests with ReTest 10 , for n equal to 3, 10 and , by varying only the n parameter of the function, updating the implementation. If necessary, create additional tests. All participants were able to complete the implementation task following the steps outlined in the procedure. Below, the results are presented according to our research questions.

To date, we carried out two studies towards to evaluate our approach for applying TDD in the development of randomized algorithms. In the first study, we were able to evaluate the feasibility of the proposed approach in a real case carrying out a single-subject experiment which involved a randomized algorithm for creation and evolution of dynamic graphs.

In single-subject experimentation, the main challenges and limitations are associated with the internal and external threats to validity Harrison Threats to internal validity concern analyses if, in fact, the treatment causes the effect Wohlin et al. The internal threats identified in this study refer to lack of statistical analysis and the effect of subject learning in the experiment. Statistical analysis usually does not apply in single-subject experiments because of the lack of replications. The analysis performed in this experiment was based on observing whether the effects of the treatment are important or not.

In the additional A Phase, the treatment is removed, and another baseline phase entered to confirm the previous findings. For sure this type of design will be considered in our future single-subject experiments. Regarding the effect of learning, the outcome of the experiment could be affected because the participant implemented the same algorithm twice, and in the second time the problem was already familiar. However, such an effect is minimized in this study, since the second code was implemented almost a year and a half after the first implementation. Threats to external validity is concerned with the generalization of the results Wohlin et al.

Performing an experiment with a single-subject allowed us to evaluate our approach from real and complex problem in machine learning field. Having a real problem, instead of a toy one, increased the external validity of the experiment, especially with regard to algorithms with non-deterministic behavior which are rarely addressed in software engineering research. Ideally, evaluation studies should involve realistic projects with various subjects, and rigor to ensure reliability on outcomes derived from the treatment that was applied Sjoberg et al. However, comparative group experiments can be time-consuming, expensive, and difficult to control mainly when involving various subjects.

Moreover, many tasks are constructed to be small toy examples in order to observe the effects of the treatment within a short period of time Harrison The biggest challenge to evaluate our approach, however, has been to find expert developers in the development of random or non-deterministic algorithms.

The single participant of this study had the appropriate developer profile for the experiment and a real case to be applied our approach. In the second study, we were able to assess the using the ReTest framework from developer experience. The purpose of the study was not to compare our approach with any other since we find out that most developers did not know how to apply TDD in randomized algorithms without a previous knowledge of the patterns. However, the proposed task was adequate to assess the use of the ReTest framework. Proper use of the framework requires knowledge in applying TDD and design patterns which is a fundamental prerequisite for TDD.

Such requirements were filled with the training performed. Certainly, the simple task and the roadmap provide to developers also helped the participants to complete their tasks, even the developers without so much experience. Through this study, we found that most developers recognized the usefulness of the framework, reporting more benefits than drawbacks. And, only two participants reported difficulties properly using the framework.

The main contribution of this paper is to present an approach to allow the use of the TDD as development and design technique of applications involving randomized algorithms, specifically when several random choices need to be made during its execution. The proposed approach consists of an extension of TDD to enable its application for algorithms with non-deterministic characteristics, based on a set of software patterns to guide the application of this approach.

In addition, a testing framework called ReTest was developed to support such algorithms in the Java programming language. Two studies were carried out to assess the feasibility of the proposed approach applied in an algorithm implementation involving multiple random decisions in sequence, and to assess the use of the Re-Test framework from the point of view of the developers. In the first study, the results of the single-subject experiment suggest that it is possible to find more bugs with the proposed approach because their patterns enable the use of TDD in random or non-deterministic algorithms, something that up to now had not been used.

Consequently, these types of algorithms can be now covered by unit tests, including regression tests. The results also suggest that the design of randomized algorithms can be improved with the proposed approach. And, the maintainability of the algorithm was another improvement aspect identified in this experiment. Also, we found that despite the difficulties, all participants were able to complete the task using the proposed approach based on provided documentation.

It is worthwhile stressing that both studies results are not intended to be conclusive statements because of their limitations and the threats to validity. Thus, all of the results reported in this paper must be confirmed with further research. Until now the results were satisfactory and indicated that the strategy is quite promising. However, further investigations are needed to verify whether such findings can be extended to cases involving i more complex tasks that better reproduce the needs and reality of the developers; ii another type of randomized algorithms in other research fields; and iii the measurement of objective variables to better evaluate the ReTest framework.

AASI: Development of the approach; Framework development; bibliographic research in TDD; design, conduction, and analysis of the second study; lead the paper writing. EMG: Development of the approach; advised in the development of the framework and the single-subject experiment; design and conduction of the second study; collaboration in the paper writing.

SMP: Development of the dynamic communities algorithm; bibliographic research in randomized algorithms; perform the single-subject experiment; collaboration in the paper writing. JC: Review of experimental software engineering concepts; collaboration in the paper writing. MGQ: Advised in the development of the single-subject experiment; bibliographic research in randomized algorithms; collaboration in the paper writing.

All authors read and approved the final manuscript.
